These modules enable intelligent control of smoke dampers with one address per damper, providing open/close commands and real-time status monitoring (Open/Closed/Fault). They include robust fault supervision and clear LED indications, supporting smoke control strategies and protected evacuation routes within Maxlogic addressable systems. Contact ANC for smoke control scenario design and supply.
Maxlogic Intelligent Addressable Smoke Damper Control Modules – supplied by Arif Alnahdi ANC are an essential part of smoke and ventilation control systems during fire emergencies. These modules are designed to manage and operate smoke dampers intelligently within addressable fire alarm systems, ensuring precise control over opening and closing air ducts and preventing smoke from spreading between building zones during emergencies.
The modules are based on intelligent addressable technology and integrate directly with addressable fire alarm control panels, allowing real-time monitoring of each damper status (Open / Closed / Fault) through the control panel or via graphical monitoring software.
Technical Specifications of the Intelligent Smoke Damper Control Module
- Product Type: Intelligent Addressable Smoke Damper Control Module
- Available Operating Voltage:
- 24V DC
- 24V AC
- 230V AC
- Number of Dampers per Module: One damper with one address
- Control Functions:
- Damper Open / Close commands
- Damper position monitoring (Open / Closed / Damper Fault)
- Circuit Supervision: Open circuit or short circuit detection in:
- Damper output line
- Remote control input line
- Position monitoring input line
- Damper Opening/Closing Time: Adjustable to 60 / 90 / 150 / 270 seconds
- Fault Detection: Fault indication if the damper status does not change within the preset time
- System Integration:
- Damper status displayed on the fire alarm control panel
- Event logging in the system event memory
- LED Indicators:
- Green: Power supply
- Yellow: Fault
- Red: Alarm
- Steady/Flashing Green: Damper open/close status
- Standards & Certifications:
- EN 54-18
- EN 54-17 (for models equipped with a Short Circuit Isolator)
Key Features of the Maxlogic Smoke Damper Control Module
- Accurate smoke control: Supports effective management of airflow and smoke movement during fire incidents.
- Full addressability: Each smoke damper has an individual address for easy identification and monitoring.
- Continuous fault monitoring: Immediate detection of any damper position or wiring faults.
- High voltage flexibility: Compatible with various types of smoke dampers.
- Support for intelligent scenarios:
- Closing dampers in other zones to prevent smoke spread
- Protecting escape routes such as stairwells through positive pressure dampers
- Integration with SPRVSR+ software: Advanced graphical monitoring and control of smoke dampers.
Recommended Applications for the Smoke Damper Control Module
- Residential and commercial towers
- Hospitals and medical centers
- Shopping malls and commercial complexes
- Underground parking areas
- Multi-storey buildings
- Facilities that rely on complex ventilation systems
Contact Arif Alnahdi ANC now to obtain certified intelligent smoke damper control modules, with a complete engineering design that ensures maximum safety and smoke control for your facility in Saudi Arabia.
